Chapter 2 The AADvance Safety Controller
software. Field devices connect direct to a controller and external
communication links over Ethernet and serial links use a secure protocol.
Physical Features A new and innovative style characteristic of the AADvance controller is the
design of the hardware. All the modules and assemblies connect together easily
without the need for inter-module wiring.
Environmental Specification
An AADvance system can be installed in a non-hazardous or a hazardous
environment. In a non-hazardous environment a system does not have to be
installed in an enclosure; however, the area where it is installed must maintain
a Pollution Degree 2 environment (IEC 60664-1).
The following environmental specification defines the minimum
environmental conditions for an AADvance controller installation. Additional
conditions apply to systems installed in a Hazardous environment.
CAUTION: The controller contains static sensitive components. When the
controller is installed attach a label that is clearly visible to tell operators to
follow anti-static precautions when they touch or move modules. Failure to
follow these instructions can result in damage to the equipment.
Table 3 - Environmental Specification
Attributes Value
Operating Temperature Range:
For use in Hazardous Environments:
Processor Modules
I/O Modules and Termination Assemblies
For use in Non-hazardous Environments:
Processor Modules, I/O modules and Termination
Assemblies
–25 °C to +60 °C (–13 °F to +140 °F)
–25 °C to +60 °C (–13 °F to +140 °F)
–25 °C to +60 °C (–13 °F to +140 °F)
Storage and Transport Temperature Range –40 °C to +70 °C (–40 °F to +158 °F)
Module Surface Temperature (during usual
operation)
43° C (109 °F) ± 2 °C
Humidity
Operating 10 % to 95 % RH, non-condensing
Storage and Transport 10 % to 95 % RH, non-condensing
Vibration
Functional Stress 5 Hz to 9 Hz
Continuous 1.7 mm amplitude
Occasional 3.5 mm amplitude
Withstand 10 Hz to 150 Hz
Acceleration 0.1 g in 3 axes
Endurance 10 Hz to 150 Hz
Acceleration 0.5 g in 3 axes
Shock 15 g peak, 11 ms duration, ½ sine
Altitude
Operating 0 to 2,000 m (0 to 6,600 ft.)
