Rockwell Automation Publication ICSTT-RM448M-EN-P - February 2021 43
Chapter 2 The AADvance Safety Controller
Expansion Cable
This is used to add extra rows of I/O base units and modules.
Table 5 - Maximum Electrical Rating Values
Module
Back-plane Electrical Ratings
Input/Output Electrical Ratings
Voltage Range (Vdc) Maximum Current (mA)
T9100 18-32 10.4A (400 mA per slot) -
T9300 18-32 9.6A (400 mA per slot) -
T9110 18-32 380 -
T9401 18-32 260 Input: 18-32 Vdc @ 24 mA
T9402 18-32 260 Input: 0-32 Vdc @ 6.5 mA
T9431 18-32 260 Input: 0-32 Vdc @ 6.5 mA
T9432 18-32 260 Input: 18-32 Vdc @ 24 mA
T9481 18-32 260 Output: 18-32 Vdc/0-20 mA
T9482 18-32 260 Output: 18-32 Vdc/0-20 mA
T9451 18-32 165
Output: 18-32 Vdc @ 0.5 A, Pilot duty 16
VA, 1.5 A Inrush
T9801 18-32 6.5 -
T9802 18-32 6.5 -
T9803 18-32 6.5 -
T9831 18-32 0-24 -
T9832 18-32 0-24 -
T9833 18-32 0-24 -
T9851 18-32 500 -
T9852 18-32 500 -
T9892 18-32 500 -
T9881 18-32 0-24 -
T9882 18-32 0-24 -
