Rockwell Automation Publication ICSTT-RM448M-EN-P - February 2021 69

Chapter 4 Before You Begin

In addition, it may be appropriate to make the following provisions:

• A lock on the door of the enclosure, to deter unauthorized access and

possible unofficial modifications.

•Lighting.

• Utility sockets.

Clear access to terminals and connectors for field, power and network wiring, and access to the wiring itself.

Clear access to the Security Dongle (Program Enable Key)
