8-8 Serial Communications
1560D-UM051D-EN-P – February 2005
Remote I/O Examples (cont.) I/O Addressing (cont.)
SMC Dialog Plus Controller Logic Control Addresses X
Bit Description I or O Slot
Y
Word
Z
Bit
[
Address
Stop O 1 16 00 O:1.16/00
Start O 1 16 01 O:1.16/01
Option Command O 1 16 02 O:1.16/02
Clear Fault O 1 16 03 O:1.16/03
SMC Dialog Plus Controller Status Addresses
X
Bit Description I or O Slot
Y
Word
Z
Bit
\
Address
Enabled I 1 16 00 I:1.16/00
Running I 1 16 01 I:1.16/01
Starting I 1 16 04 I:1.16/04
Stopping I 1 16 05 I:1.16/05
Fault I 1 16 07 I:1.16/07
At Speed I 1 16 08 I:1.16/08
SMC Dialog Plus Controller Feedback Address X
I or O Slot
Y
Word
Z
Address
I 1 17 I:1.17
X The addresses shown are example-specific. Addresses for any given installation can be
determined, based upon the 1203-GD1 communication module switch settings for: rack
address, starting group number, block transfer, logic commands/status, and
reference/feedback by applying the I/O addressing format for SLC 500 controllers.
Y The 1747-SN scanner resides in slot 1.
Z
Based on the 1203-GD1 communication module switch settings (rack 2, starting group 0).
Refer to the 1747-SN User Manual, Publication 1747-6.6.
[ Refer to Table 8.A.
\ Refer to Table 8.B.
