10-26 Troubleshooting
1560D-UM051D-EN-P – February 2005
Figure 10.18 – 3300 and 4160V Heatsink Module, 600A
Figure 10.19 – 6900V Heatsink Module, 600A
Snubber Resistors
Heatsink Assembly
Sharing Resistors
Gate Driver Board
Snubber Capacitors
Snubber Resistors
Heatsink Assembly
Sharing Resistors
Gate Driver Board
Snubber Capacitors
Snubber Resistors
Heatsink Assembly
Sharing Resistors
Snubber Capacitor
Frame Assembly
Gate Driver Boards
Snubber Capacitor
Snubber Resistors
Heatsink Assembly
Sharing Resistors
Snubber Capacitor
Frame Assembly
Gate Driver Boards
Snubber Capacitor
