B-8 Spare Parts
1560D-UM051D-EN-P – February 2005
Table B.8
Bulletin 1503D, 1560D, 1562D • 5500/6900 Volt, 180/360 Amp, 18-device
Qty per controller Description Part Number
180 A
6 180A : Matched Set 3 SCRs DCR820 or 5STP03D6500 80156-893-73-R
360 A
6 360A : Matched Set 3 SCRs DCR1020 or 5STP08G6500 80156-894-73-R
Common Components
80165-898-52
9
SCR Gate Driver Board
(2 devices)
80165-898-55
3 IGDPS Board 80026-044-03
1 5500V 80165-878-55
2 / 3
Voltage Divider Resistor Board
5500V / 6900V 80165-878-51
1 Voltage Feedback Circuit Board 80165-938-54
120 V 80187-131-52
1
MV SMC Interface Circuit Board
Assembly – Series B
230 V 80187-131-54
Brick type 80025-871-04
9 Snubber Resistor 60 ohm
Wire wound type 80025-760-02
9 Snubber Capacitor 0.68 µF 80025-812-02
9 Sharing Resistor 32.5K, 225W 80025-753-01
2.5 m 80025-549-03
21 Fiber-optic Cable
5.0 m 80025-549-01
2 Bridge Rectifier 24808-451-01
120 V 80145-581-02
2 MOV
230 V 80145-581-07
120V AC (North America) 80187-051-51
1 Test Power Supply
Universal 80187-245-51
6 Voltage Divider Resistors, 74K 100W 80025-588-05
110/120 V AC 80154-991-59
1 LV Control Panel
220/230 V AC 80187-226-52
3 Power Fuses Consult Engineering Data
2 CPT Primary Fuses Consult Engineering Data
1 LV Fuses Consult Engineering Data
3 Heater Elements Consult Engineering Data
2 20 Amp Contact Cartridge 700-CPM
3 1-pole Blade Assembly (400 Amp) 80145-566-51
Special Lubricant (for Blade Assembly, 400 Amp) 80158-357-51
If desired, a complete factory assembled SCR/heatsink assembly can be purchased rather than individual SCRs.
See table below for part numbers :
Qty per controller Description Part Number
3 180 Amp, 6900 Volt Controller 80187-277-51
3 360 Amp, 6900 Volt Controller 80187-277-52
Requires a thin film of electrical joint compound between base and mounting surface. Available with SCR replacement parts
or separately as Part Number 80025-783-51.
1562D only.
Reference only. 1503D – For OEM products, refer to OEM-supplied documentation for specific spare parts list.
1560/1562D are Allen-Bradley manufactured starters. Refer to Service Manual for specific spare parts list.
Used when options 13XA (Soft Stop) or 13XB (Pump Control) are not provided.
Used when options 13XA (Soft Stop) or 13XB (Pump Control) are provided.
Not provided if IntelliVAC is used (refer to Publication 1503-UM051A-EN-P for spare part information on IntelliVAC).
