Spare Parts B-9
1560D-UM051D-EN-P – February 2005
Table B.9
Bulletin 1503D, 1560D, 1562D • 5500/6900 Volt, 600 Amp, 18-device

Qty per controller Description Part Number
3 Heatsink Assembly 600A with Thermistor 80187-285-51
Note : Due to stringent torquing specifications in this application, it is MANDATORY that the entire heatsink assembly
be replaced. Contact the Rockwell Automation factory.

80165-898-52
9
SCR Gate Driver Board
(2 devices)

80165-898-55
3 IGDPS Board  80026-044-03
1 5500V 80165-878-55
2 / 3
Voltage Divider Resistor Board
5500V / 6900V 80165-878-51
1 Voltage Feedback Circuit Board 80165-938-54
120 V 80187-131-52
1
MV SMC Interface Circuit Board
Assembly – Series B
230 V 80187-131-54
Brick type 80025-871-04
18 Snubber Resistor 60 ohm
Wire wound type 80025-642-04
9 Snubber Capacitor 1.0 µF 80025-812-01
9 Sharing Resistor 32.5K, 225W 80025-753-01
2.5 m 80025-549-03
21 Fiber-optic Cable
5.0 m 80025-549-01
2 Bridge Rectifier 24808-451-01
120 V 80145-581-02
2 MOV
230 V 80145-581-07
120V AC (North America) 80187-051-51
1 Test Power Supply
Universal 80187-245-51
6 Voltage Divider Resistors, 74K 100W 80025-588-05
110/120 V AC   80154-991-59
1 LV Control Panel
220/230 V AC  80187-226-54
3 Power Fuses  Consult Engineering Data
2 CPT Primary Fuses  Consult Engineering Data
1 LV Fuses Consult Engineering Data
3 Heater Elements  Consult Engineering Data
2 20 Amp Contact Cartridge  700-CPM
600 A 80157-709-51
3
Isolating Switch Blade Assembly
1-pole (moving blade assembly)
800 A
Consult the Rockwell
Automation factory
600 A 80157-710-51
3
Isolating Switch Blade Assembly
1-pole (fixed blade assembly)
800 A
Consult the Rockwell
Automation factory
Special Lubricant (for Blade Assembly) 80158-357-51
 1562D only.
 Reference only. 1503D – For OEM products, refer to OEM-supplied documentation for specific spare parts list.
1560/1562D are Allen-Bradley manufactured starters. Refer to Service Manual for specific spare parts list.
 Used when options 13XA (Soft Stop) or 13XB (Pump Control) are not provided.
 Used when options 13XA (Soft Stop) or 13XB (Pump Control) are provided.
 Not provided if IntelliVAC control is used (refer to Publication 1503-UM051A-EN-P for spare part information on IntelliVAC).
