2-6 Installation
1560D-UM051D-EN-P – February 2005
Power Connections (cont.)
Phase 1 Module
Phase 1 Line Connection
Phase 1 Load Connection
Phase 2 Module
Phase 3 Module
Phase 2 Line Connection
Phase 2 Load Connection
Phase 3 Line Connection
Phase 3 Load Connection
Bypass Contactor
Phase 1 Module
Phase 1 Line Connection
Phase 1 Load Connection
Phase 2 Module
Phase 3 Module
Phase 2 Line Connection
Phase 2 Load Connection
Phase 3 Line Connection
Phase 3 Load Connection
Bypass Contactor
Figure 2.2 – Power Connections • 1560D – 180/360A, 6900 V
