Rockwell Automation Publication 1734-UM013J-EN-P - July 2014 105
Chapter 6
Configure the Module for a SmartGuard
Controller
This chapter provides information about how to configure a SmartGuard
controller and POINT Guard I/O modules by using USB (Universal Serial Bus)
connectivity. Refer to the corresponding RSNetWorx for DeviceNet software
help files for network-configurator operating procedures.
Before You Begin
Be sure you have these required items:
• RSNetWorx for DeviceNet software
• RSLinx® software, version 2.51 or later
• SmartGuard USB driver
The SmartGuard USB driver should already be in your RSLinx software. If
it is not, load the driver onto your computer, noting the folder location as
you need to browse to it later.
• Personal computer with a Microsoft Windows 2000,
MicrosoftWindows 2000 Terminal Server, or MicrosoftWindows XP
operating system
• 1734-PDN adapter
• SmartGuard controller and POINT Guard I/O module EDS files
Topic Page
Before You Begin 105
Set the Node Address 106
Auto-addressing with a 1734-PDN Adapter 108
Set Up Your DeviceNet Network 109
Configure the POINT Guard I/O Modules 110
Configure the SmartGuard Controller 119
Save and Download Module Configuration 124
For information about RSNetWorx for DeviceNet software, from the Help
menu, choose RSNetWorx Help.
Cat. No. Required Version
1734-IB8S, 1734-OB8S 9 or later
1734-IE4S 10 or later
