192 Rockwell Automation Publication 1734-UM013J-EN-P - July 2014
Appendix F I/O Assemblies
Output Assemblies
Analog Input Assemblies
Table 22 - 1734-OB8S Input Assemblies
Instance
Decimal (hex)
Connection
Type
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
580 (244h) Safety and
Standard
0 Safety Output 7 Safety Output 6 Safety Output
5
Safety Output
4
Safety Output
3
Safety Output
2
Safety Output
1
Safety Output
0
1028 (404h) Safety and
Standard
0 Safety Output 7 Safety Output 6 Safety Output
5
Safety Output
4
Safety Output
3
Safety Output
2
Safety Output
1
Safety Output
0
1Safety Output
Monitor 7
Safety Output
Monitor 6
Safety Output
Monitor 5
Safety Output
Monitor 4
Safety Output
Monitor 3
Safety Output
Monitor 2
Safety Output
Monitor 1
Safety Output
Monitor 0
1044 (414h) Safety and
Standard
0Safety Output
Monitor 7
Safety Output
Monitor 6
Safety Output
Monitor 5
Safety Output
Monitor 4
Safety Output
Monitor 3
Safety Output
Monitor 2
Safety Output
Monitor 1
Safety Output
Monitor 0
1 Reserved Combined
Output
Reserved Output Power
Error
Reserved
Table 23 - Output Assemblies for all POINT Guard I/O Modules
Instance Decimal
(hex)
Module Connection
Type
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
33 (21h) 1734-IB8S Safety
(1)
0
Reserved
Standard
Output 3
Standard
Output 2
Standard
Output 1
Standard
Output 0
564 (234h) 1734-OB8S Safety Only 0 Safety
Output 7
Safety
Output 6
Safety
Output 5
Safety
Output 4
Safety
Output 3
Safety
Output 2
Safety
Output 1
Safety
Output 0
770 (302h) 1734-IE4S Safety 0 Reserved Reserved Reserved Reserved Reset Tach
3
(2)
Reset Tach
2
(2)
Reset Tach
1
(2)
Reset Tach
0
(2)
(1) Only outputs 1 and 3 are configurable to Muting or Test Outputs. This assembly is accessible only over a Safety connection.
(2) When set (1), this bit specifies a reset of an overfrequency condition on the tachometer counter. Clear this bit to allow the tachometer channel to operate.
Table 24 - 1734-IE4S Input Assemblies
Instance
Decimal (hex)
Connection
Type
Byte High Byte Low Byte
402 (192h)
Safety and
Standard
0, 1 Input 0 Input 0
2, 3 Input 1 Input 1
4, 5 Input 2 Input 2
6, 7 Input 3 Input 3
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
8 Reserved Reserved Reserved Reserved Ch 3 Input
Status
Ch 2 Input
Status
Ch 1 Input
Status
Ch 0 Input
Status
