Rockwell Automation Publication 1734-UM013J-EN-P - July 2014 123

Configure the Module for a SmartGuard Controller Chapter 6

Complete the Set Up of the SmartGuard Controller

1. From the 1752-L24BBB dialog box, click Apply and then OK to accept

the connection.

2. Place RSNetWorx from DeviceNet software back into Online mode.

a. If you see this dialog box, click Yes to save changes.

b. Click OK to upload or download device information.

You see the following nodes after the browse.
