124 Rockwell Automation Publication 1734-UM013J-EN-P - July 2014
Chapter 6 Configure the Module for a SmartGuard Controller
Save and Download Module
Configuration
We recommend that after a module is configured you save your work
If the MS and NS status indicators on the POINT Guard I/O module are not
both solid green after download, ownership may have been lost. The ownership is
based on the following:
• POINT Guard I/O module number
• POINT Guard I/O safety network number
• SmartGuard slot number
• SmartGuard safety network number
• Path from SmartGuard controller to POINT Guard I/O module
• Configuration signature
If any of these change, the connection between the SmartGuard controller and
the POINT Guard I/O module is lost, and a yellow yield icon appears in the
RSNetWorx for DeviceNet tree. For more information, see Chapter 8
.
If you have not followed the configuration guidelines in the parameter tables
found in Configure Safety Analog Inputs
on page 114, the error message
“Invalid Configuration Parameter? occurred while attempting to configure the
safety device” appears in the Error Log during download.
