182 Rockwell Automation Publication 1734-UM013J-EN-P - July 2014

Appendix D Safety Data

Series A Safety Data

Figure 60 - PFD versus Proof Test Interval for 1734-IE4S Series A

Figure 61 - PFD vs. Proof Test Interval 1734-IB8S Series A

1.00E-07

1.00E-06

1.00E-05

1.00E-04

1.00E-03

1.00E-02

0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21

1% of SIL 3 Limit

10% of SIL 3 Limit

Proof Test Interval (years)

PFD

Proof Test Interval [years]

PFD
