Rockwell Automation Publication 1734-UM013J-EN-P - July 2014 151

Appendix A

Indicators

Figure 47 - Indicators Placement

Topic Page

Module 152

Network Status 152

Configuration Lock 152

Power 153

1734-IE4S Sensor Power 153

1734-IE4S Safety Analog Input Status 153

1734-IB8S Safety Input Status 153

1734-OB8S Safety Output Status 154

Module Network

Power

Input/Output 0

Input/Output 1

Input/Output 2

Input/Output 3

Input/Output 5

Input/Output 6

Input/Output 7

Input/Output 4

Configuration Lock

1734-IB8S or 1734-OB8S

Module Network

Power

Input 0

Input 1

Sensor 0

Sensor 1

Input 3

Sensor 2

Sensor 3

Input 2

Configuration Lock

1734-IE4S
