170 Rockwell Automation Publication 1734-UM013J-EN-P - July 2014

Appendix C Specifications

Figure 54 - Frequency Response of Voltage Input with Filter = 1 Hz

Figure 55 - Frequency Response of Voltage Input with Filter = 5 Hz

0.01 0.10 1.00 10.00 100.00 10000.001000.00

-30

-20

-10

-40

-70

8 0

-60

-50

-90

Frequency (Hz)

Frequency Response (dB)

ADC resolution = -72.2 dB

0.01 0.10 1.00 10.00 100.00 10000.001000.00

-30

-20

-10

-40

-70

8 0

-60

-50

-90

Frequency (Hz)

Frequency Response (dB)

ADC resolution = -72.2 dB
