Rockwell Automation Publication 1734-UM013J-EN-P - July 2014 49
Guidelines for Placing Power Supplies and Modules in a System Chapter 3
To implement a system containing only 1734-IB8S Series B and 1734-OB8S
Series B POINT Guard I/O modules (no POINT Guard I/O Series A modules
used), follow these guidelines.
• Series B POINT Guard I/O modules are used without 1734-CTM spacer
modules with ambient operation up to 55
°C (131 °F) See Te c h n i c a l
Specifications for Series B Modules for Series B POINT Guard I/O
module derating requirements for every module with ambient operation
between 40
°C (104 °F) and 55 °C (131 °F).
Figure 23 - Placing Series B Digital Modules for up to 55 °C (131 °F) Operation
ATTENTION: Vertical orientation requires careful attention to design details
and panel layout so that all modules in the stack operate within their rated
operating temperature range.
1734-AENT 1734-OB8S/B 1734-IB8S/B 1734-OB8S/B 1734-IB8S/B 1734-OB8S/B 1734-IB8S/B
5.08 cm (2 in.)
