System Mode (Settings Common to All Modes)
fig.08-23.eps_50
D Beam
Parameter
Value Description
D Beam Local Sw
(V-LINK D Beam Local Switch)
OFF, ON
Specifies whether the D Beam controller will be disconnected from the inter-
nal sound generator in V-LINK mode (OFF) or not disconnected (ON).
1–4 Assign L, R
(V-LINK D Beam1–4 Assign L, R)
Specify the V-LINK function that
will be controlled when you oper-
ate the D Beam controller. Assign
L is the left side, and Assign R is
the right side.
OFF The D Beam controller will not be used.
PLAYBACK-
SPEED
Playback speed
DISSOLVE-
TIME
Dissolve time (time over which the image switches)
AUDIO LEVEL Volume during audio playback
COLOR-CB Color Cb (color-difference signal)
COLOR-CR Color Cr (color-difference signal)
BRIGHTNESS Brightness
VFX1 Visual effects 1
VFX2 Visual effects 2
VFX3 Visual effects 3
VFX4 Visual effects 4
OUTPUT-FADE Output fade
