233
Utility Mode
Perform this adjustment if the D Beam controller is functioning incorrectly, such as responding even though you have
not operated it.
1.
In the Utility Menu screen, touch <Calibration>.
The Calibration screen appears.
fig.09-30-ps.eps_50
2.
Touch <D Beam>.
The D Beam Calibration screen appears.
fig.09-33-ps.eps_50, fig.09-39.eps
When you place your hand over the D Beam controller, the “L” or “R” level meter in the screen will move upward
or downward.
3.
First specify the location at which the D Beam controller will begin responding (i.e., the minimum value).
Move your hand toward the D Beam controller, and touch <Min> at the point where you want the controller to
begin responding.
4.
Next specify the location at which the D Beam controller will reach the peak (i.e., the maximum value).
Continue moving your hand toward the D Beam controller, and touch <Max> at the point where you want the
peak response to occur.
5.
While watching the level meter in the screen, raise and lower your hand to check the response of the D Beam
controller.
6.
If you are satisfied with the response, touch <OK>.
The sensitivity of the D Beam controller will be calibrated.
Adjusting the Sensitivity of the D Beam Controller
V-Synth-GT_e.book 233 ページ ２００７年４月９日 月曜日 午後１時４６分
