Table 11. 7352 front panel elements
LED Description
PWR LED • Off: Off.
• Red: Boot up in process.
• Green: On.
OPT LED Not used in this model.
DIR LED • Off: The AP is not being managed by ZoneDirector (standalone
mode).
• Green: The AP is being managed by ZoneDirector.
• Slow flashing green (one flash every two seconds): The AP is being
managed by ZoneDirector, but is currently unable to communicate
with ZoneDirector.
• Fast flashing green (two flashes every second): The AP is being
managed by ZoneDirector and is currently receiving configuration
settings (provisioning) or an image update.
WLAN LED • Off: The WLAN service is down.
• Amber: The WLAN service is up and no clients are associated
(standalone), or no wireless clients and no downlink MAPs are
connected (RAP).
• Green: The WLAN service is up and at least one wireless client is
associated. If Mesh is enabled, no downlink MAPs are connected.
•
Fast flashing green: The WLAN service is up, at least one client
is associated, and at least one Mesh downlink is connected.
• Slow flashing green: At least one Mesh downlink is connected, and
no clients are associated.
AIR LED •
Off: The AP is operating in standalone mode or operating as a root
AP (RAP) or a non-mesh AP.
•
Green: The AP is functioning as a RAP or MAP and the uplink
signal is good.
•
Slow flashing green (one flash every two seconds): Mesh
networking is enabled, but the AP is still searching for a mesh
uplink.
•
Fast flashing green (two flashes every second): The AP is
functioning as a MAP and the wireless signal to its uplink AP is
fair.
