Introducing the Ruckus Wireless AP
Getting to Know the AP Features
Ruckus Wireless Indoor AP 100.2.0 User Guide, 800-70892-001 Rev A 30
Rear Panel
Figure 11 shows the rear panel of the 7352 (and 7372). For a description of each
rear panel part, refer to Ta b l e 1 2.
Figure 11. 7352/7372 rear panel
Table 12. 7352/7372 rear panel elements
Number Item Name Description
1 10/100/1000+PoE
Port
One RJ-45 port for a 10/100/1000 PoE (Power over
Ethernet, 802.3af) connection.
2 10/100 Port One RJ-45 port for a 10/100 connection.
3 Power Connect the power adapter (12 VDC/1.25A) to this
socket. Power can also be supplied via the 10/100/
1000 PoE port.
4 RST Button Pressing, and then quickly releasing this internal button
reboots the AP. Pressing and holding it for six seconds
resets the AP to factory default settings.
CAUTION! Resetting the AP to factory default
settings erases all previously configured settings.
