Introducing the Ruckus Wireless AP
Getting to Know the AP Features
Ruckus Wireless Indoor AP 100.2.0 User Guide, 800-70892-001 Rev A 32
DIR LED • Off: The AP is not being managed by ZoneDirector (standalone
mode).
• Green: The AP is being managed by ZoneDirector.
• Slow flashing green (one flash every two seconds): The AP is
being managed by ZoneDirector, but is currently unable to
communicate with ZoneDirector.
• Fast flashing green (two flashes every second): The AP is being
managed by ZoneDirector and is currently receiving
configuration settings (provisioning) or an image update.
2.4G LED (WLAN) • Off: The WLAN service is down.
• Green: The WLAN service is up, at least one client is associated,
and signal quality is good (RSSI >= 15).
• Flashing green (two flashes every second): The WLAN service
is up but no clients are associated.
• Amber: The WLAN service is up, at least one client is
associated, but signal quality is poor (RSSI < 15).
5G LED (WLAN)
• Off: The WLAN service is down.
• Green: The WLAN service is up, at least one client is associated
(standalone), or at least one downlink MAP is connected (RAP),
or uplink RAP is connected (MAP), and signal quality is good
(RSSI >= 15).
• Fast flashing green (two flashes every second): The WLAN
service is up but no clients are associated (standalone), no
downlink MAPs are connected (RAP), or no uplink RAP is
connected (MAP).
• Amber: The WLAN service is up, at least one wireless client is
associated (standalone), or at least one downlink MAP is
connected (RAP), or uplink RAP is connected (MAP), but signal
quality is poor (RSSI < 15).
Table 13. 7363 front panel elements (Continued)
LED Description
