Introducing the Ruckus Wireless AP
Getting to Know the AP Features
Ruckus Wireless Indoor AP 100.2.0 User Guide, 800-70892-001 Rev A 46
WARNING! For units with Power over Ethernet (PoE). These products and all
interconnected equipment must be installed indoors within the same building,
including the associated LAN connections, as defined by Environment A of the IEEE
802.3af Standard.
Table 20. 7982 rear panel elements
Number Item Name Description
1 ETHERNET +
PoE Port
One RJ-45 port for a 10/100/1000 PoE (Power over
Ethernet, 802.3af/at) connection (
Note).
2 ETHERNET Port One RJ-45 port for a 10/100/1000 connection.
3 12V 1.5A Power
Socket
Connect the power adapter (12 VDC/1.25A) to this socket.
Power can also be supplied via the ETHERNET + PoE port.
4 RESET Button Pressing, and then quickly releasing this internal button
reboots the AP. Pressing and holding it for six seconds
resets the AP to factory default settings.
CAUTION! Resetting the AP to factory default settings
erases all settings that you configured previously.
Note:
Class 4 device. Some PoE+ switches reserve 30W for Class 4 device by default.
Table 21. Behavior of Ethernet port LEDs on 7982
LEDs Description
Off Not connected
Amber + Green Connected to 10Mbps device
Amber Connected to 100Mbps device
Green Connected to 1000Mbps device
