Introducing the Ruckus Wireless AP
Getting to Know the AP Features
Ruckus Wireless Indoor AP 100.2.0 User Guide, 800-70892-001 Rev A 54
Table 26. R300 front panel elements
LED Description
PWR LED • Off: Off.
• Red: Boot up in process.
• Green: On.
OPT LED Not used in this model.
DIR LED • Off: The AP is not being managed by ZoneDirector
(standalone mode).
• Green: The AP is being managed by ZoneDirector.
• Slow flashing green (one flash every two seconds): The AP is
being managed by ZoneDirector, but is currently unable to
communicate with ZoneDirector.
• Fast flashing green (two flashes every second): The AP is being
managed by ZoneDirector and is currently receiving
configuration settings (provisioning) or an image update.
2.4G LED (WLAN) • Off: The WLAN service is down.
•
Green: The WLAN service is up and at least one client is
associated.
•
Amber: The WLAN service is up and no clients are associated.
5G LED (WLAN) • Off: The WLAN service is down.
•
Green: The WLAN service is up and at least one client is
associated.
•
Amber: The WLAN service is up and no clients are associated.
