3 12V 2A Power
Socket
Connect a customer-ordered Ruckus Wireless 12VDC 902-
1169-xx00 AC power adapter (sold separately). When powered
by the 902-1169-xx00 power adapter, the R710 supports a full
feature set.
(Power can alternately be supplied via the Ethernet + PoE port.)
4 RESET Button Pressing, and then quickly releasing this internal button reboots
the AP. Pressing and holding it for six seconds resets the AP to
factory default settings.
CAUTION! Resetting the AP to factory default settings erases
all settings that you configured previously.
5 USB Port The R710 can have a low-power (0.5W or less) customer-
supplied USB device plugged in. The USB device is hidden after
the R710 is attached to its mounting base.
Table 39. Behavior of Ethernet port LEDs on the R710
LEDs Description
Off Not connected
Amber + Green Connected to 10Mbps device
Amber Connected to 100Mbps device
Green Connected to 1000Mbps device
Table 38. R710 rear panel elements (Continued)
No. Item Name Description
