32 Cubis
®
MCE Operating Instructions
System Settings
Parameters in the “Leveling” Submenu
Parameters Setting values Explanation
LEVEL OFF The device does not display messages on the status of the level.
NOTE* The [LEVELING] display flashes if the device needs to be leveled.
ERR.MSG. The [LEVEL.ERR.] message appears in the operating display if the device has not been
leveled.
START KEY Sets the trigger for leveling to “key”: Leveling must be started manually by pressing
the [Leveling] button.
AUTO* Sets the trigger for leveling to “automatic”: The device automatically performs a
leveling function using the integrated sensor before every internal
calibration / adjustment.
* Factory setting
Parameters in the “Sensor” Submenu
Parameters Setting values Explanation
CONTROL OFF Deactivates the motion sensor: No gestures are recognized.
ON* Activates the motion sensor.
NUM.GEST. 2 GESTUR.* Activates the control of functions with 2 gestures. Gestures: Left, right
4 GESTUR. Activates the control of functions with 4 gestures. Gestures: Left, right, top, bottom
LEFT CMD. PRINT* Left command of the gesture control corresponds to the [Print] key.
ZERO Left command of the gesture control corresponds to the [Zero] key.
TARE Left command of the gesture control corresponds to the [Tare] key.
NONE No function is assigned to the left command of the gesture control.
RIGHT.CMD. PRINT* Right command of the gesture control corresponds to the [Print] key.
ZERO Right command of the gesture control corresponds to the [Zero] key.
TARE Right command of the gesture control corresponds to the [Tare] key.
NONE No function is assigned to the right command of the gesture control.
UP.CMD. PRINT* Upper command of the gesture control corresponds to the [Print] key.
ZERO Upper command of the gesture control corresponds to the [Zero] key.
TARE Upper command of the gesture control corresponds to the [Tare] key.
NONE No function is assigned to the upper command of the gesture control.
DOWN.CMD. PRINT* Lower command of the gesture control corresponds to the [Print] key.
ZERO Lower command of the gesture control corresponds to the [Zero] key.
TARE Lower command of the gesture control corresponds to the [Tare] key.
NONE No function is assigned to the lower command of the gesture control.
* Factory setting
Parameters in the “COM-RS232” Submenu
Parameters Setting values Explanations
DAT.REC. SBI.WEIGH. Enables a faster SBI communication, only for software commands to the weighing
module.
XBPI Extended range of commands to control numerous balance functions with binary
protocol for direct communication with the weighing module.
SBI* Enables SBI communication. The data is output to a PC or control unit. Enables the
use of ESC commands from a PC to control the basic balance functions with ASCII
protocol.
OFF Deactivates the automatic data output.
* Factory setting
