Cubis

MCE Operating Instructions 33

System Settings

Parameters Setting values Explanations

BAUD 600 Sets the baud rate to 600 baud.

1200 Sets the baud rate to 1200 baud.

2400 Sets the baud rate to 2400 baud.

4800 Sets the baud rate to 4800 baud.

9600* Sets the baud rate to 9600 baud.

19200 Sets the baud rate to 19200 baud.

38400 Sets the baud rate to 38400 baud.

57600 Sets the baud rate to 57600 baud.

115200 Sets the baud rate to 115200 baud.

PARITY ODD* Applies an odd parity.

EVEN Applies an even parity.

NONE Does not apply a parity.

STOPBIT 1 BIT* Sets the number of stop bits to 1.

2 BITS Sets the number of stop bits to 2.

HANDSHK. SOFTWARE Sets the handshake protocol to software handshake.

HARDWARE* Sets the handshake protocol to hardware handshake.

NONE Does not set a handshake protocol.

DATABIT 7 BITS Sets the number of data bits to 7.

8 BITS* Sets the number of data bits to 8.

* Factory setting

Parameters in the “PC-USB” Submenu

Parameters Setting values Explanations

DAT.REC. SBI.WEIGH. Enables a faster SBI communication, only for software commands to the weighing

module.

XBPI Extended range of commands to control numerous balance functions with binary

protocol for direct communication with the weighing module.

SBI* Enables SBI communication. The data is output to a PC or control unit. Enables the

use of ESC commands from a PC to control the basic balance functions with ASCII

protocol.

PC.SPREAD. Enables data output to a spreadsheet program via a direct PC connection.

PC.TEXT Enables a direct PC connection to be established to a text processing program.

OFF Deactivates the data output.
