SATEL INTEGRA Plus 29
opens the “Configuration” window, if the program does not communicate with the
control panel, or communicates with it through COM port or modem. Otherwise, the
current connection window will open.
Opening the
“Configuration” window will close the COM port, which was
previously selected for communication. Closing the window will open the COM
port.
opens the drop-down menu, where you can select the method of establishing
communication between the program and the alarm control panel.
− enables/disables the COM port,
− opens the connection information window (remote programming).
Color of the button icon has the following meanings:
green – ready to send data,
alternating green and yellow – data transmission in progress,
red – no communication with the control panel,
gray – COM port disabled.
3.2 Parameters related to communication between the control panel and
DLOADX program
3.2.1 Communication identifiers
The DLOADX program will establish communication with the control panel if:
– the communication identifiers in the control panel have their factory default value – the
program will suggest then randomly generated identifiers (which you can accept or
enter your own ones),
– the communication identifiers in the program and in the control panel are identical.
Programming the communication identifiers
The identifiers can be programmed:
• keypad: functions available in the SM SETTINGS submenu (SERVICE MODE SM SETTINGS).
• DLOADX program: “Connection settings” window (the command for opening this window is
available in the “Communication” menu; you can also use the Ctrl+R key combination).
Description of communication identifiers
INTEGRA identifier – identifier of the alarm control panel. It must consist of 10 characters
(digits or letters from A to F). It makes it possible to recognize the control panel and match
a data file to it, if the data file has been saved on the computer. Do not program the same
identifier for different control panels which are operated from the same computer (the
DLOADX program will be incapable of distinguishing between them).
DLOADX identifier – identifier of the computer with DLOADX program. It must consist of 10
characters (digits or letters from A to F). The control panel will only establish connection
with the program which uses the valid identifier.
