10.2.2 Reporting via Ethernet network
The ETHM-1 / ETHM-1 Plus module must be connected to the control panel.
Events in TELIM format cannot be sent through Ethernet network.
1. Enable the REPORTING - ETHM-1 / REPORTING – ETHM/INT-GSM option.
2. Determine whether the event codes will be sent to both monitoring stations or to one of
them only (STATION 1 OR 2 / STATION 1 / STATION 2 / STATION 1 AND 2). If the INT-GSM
module is connected to the ETHM-1 Plus module, you can select the DUAL PATH REPORTING
option.
3. Program the following for the monitoring station to which event codes are to be sent:
– reporting format in which the codes will be sent,
– server address,
– port number,
– IP format in which the codes will be sent (SATEL or SIA-IP),
– encryption key (STATION KEY) and control panel identifier for the purposes of reporting
via Ethernet (ETHM KEY) if the SATEL format is selected,
– additional parameters if the SIA-IP format is selected,
– identifiers with which the events will be sent,
– event assignment (if STATION 1 AND 2 is selected),
– advanced options if SIA reporting format is selected.
4. If a reporting format other than CONTACT ID (FULL) or SIA (FULL) is selected:
– assign identifiers to the partitions, zones, keypads and expansion modules,
– program the codes for events which are to be reported.
5. Define the parameters of test transmissions.
6. If the INT-GSM module is connected to the ETHM-1 Plus module, define the priority of
Ethernet reporting in the ETHM-1 Plus module settings.
10.2.3 GPRS reporting
The TELIM format events cannot be sent using the GPRS technology.
The GPRS settings (APN, username, password, DNS server) must be programmed in
the INT-GSM / GSM module.
Reporting by using the INT-GSM module
1. Enable the REPORTING – ETHM/INT-GSM option.
2. Determine whether the event codes will be sent to both monitoring stations or to one of
them only (STATION 1 OR 2 / STATION 1 / STATION 2 / STATION 1 AND 2). If the INT-GSM
module is connected to the ETHM-1 Plus module, you can select the DUAL PATH REPORTING
option.
3. Program the following for the monitoring station to which event codes are to be sent:
– reporting format in which the codes will be sent,
– server address,
– port number,
– IP format in which the codes will be sent (SATEL or SIA-IP),
– encryption key (STATION KEY) and control panel identifier for the purposes of reporting
via Ethernet (ETHM KEY) if the SATEL format is selected,
– additional parameters if the SIA-IP format is selected,
– identifiers with which the events will be sent,
