SATEL INTEGRA Plus 87
Identifiers
Each event code is sent to the monitoring station with an identifier. Up to 8 identifiers plus a
system identifier can be programmed. Sent with the system identifier are events related to
the alarm system (troubles, tests, etc.).
4 characters (digits or letters from A to F) must be programmed for each identifier. Using the
digit 0 in the identifier is not recommended.
For the pulse, ADEMCO EXPRESS, CONTACT ID (SELECTED) or SIA (SELECTED) formats, you must
define which events will be sent with the given identifier (see: “Identifiers assignment”).
For the CONTACT ID (FULL) or SIA (FULL) formats, each object has its own identifier.
Therefore, the identifiers of non-existing objects need not to be programmed. In the
system event identifier field, you should re-enter the identifier of the object which is
responsible for the system (for example, the object, where the control panel is
installed).
SIA / TELIM prefix
2 characters which will precede each of the identifiers in case of the SIA and TELIM formats.
Thus an identifier consisting of 6 characters can be obtained. 2 hexadecimal characters
(digits or letters from A to F) can be programmed. Entering 00 means that the prefix will not
be added. Using the digit 0 in the prefix is not recommended.
Events assignment
If the events are to be sent to both stations (STATION 1 AND 2 is selected), you can define
which event types will be reported to the given station.
It is not possible to assign events for the CONTACT ID (FULL) and SIA (FULL) formats.
10.1.3 SIA-IP
If events are to be sent in the SIA-IP format, you must program additional parameters for
each monitoring station.
Send MAC address [MAC] – if this option is enabled, the MAC address of ETHM-1 /
ETHM-1 Plus module will be sent with event code.
Send timestamp [Timestamp] – if this option is enabled, the date and time will be sent with
event code (the monitoring station can change the date and time in the control panel).
Encrypt data [Coded] – if this option is enabled, the data to be sent will be encrypted, and
the date and time will be sent with event code (the monitoring station can change the date
and time in the control panel).
SIA-IP key – the key to encrypt data to be sent using the SIA-IP format.
hex – if the option is enabled, you can enter up to 32 hexadecimal characters as the SIA-IP
KEY
. If the option is disabled, you can enter up to 16 alphanumeric characters as the
SIA-IP KEY.
SIA-IP acct – a string of up to 16 hexadecimal characters, which is used to identify the
control panel for the purpose of reporting in SIA-IP format.
Supervision interval [SIA-IP test] – an additional transmission can be sent at specified
intervals to check communication with the monitoring station. You can program a number
of days, hours, minutes and seconds between the transmissions.
10.1.4 Identifiers assignment
Define the identifier with which events relating to individual partitions, zones, keypads and
expansion modules will be sent. If no identifier is assigned to the given element of the
system, it will be impossible to define codes for events relating to it.
