48 Programming SATEL
• in the DLOADX program connected to the control panel, in the “Structure” window,
“System” tab, after clicking on the partition name and then on the “Partition timer” button.
4.3 Zones
The zone is a separated portion of the protected area which can be supervised by a detector
or detectors. A zone can only be assigned to one partition.
The system supports the following zones:
• hardwired – on the control panel electronics board, in keypads and expanders.
The number of available hardwired zones is determined by the control panel during
identification procedure.
• wireless – when the ABAX 2 / ABAX wireless system controller is connected. The number
of available wireless zones depends on the number of wireless devices registered in the
system and is determined during the procedure of adding the devices.
• virtual – zones which physically do not exist, but have been programmed as FOLLOW
OUTPUT
or are controlled by means of a keyfob.
4.3.1 Assigning zones to a partition
The zones can be assigned to a partition:
• using the keypad, in the service mode, by means of the ZONES function (STRUCTURE
SYSTEM PARTITIONS SETTINGS [Part. Name] ZONES) – see: “Selection from the
multiple-choice list” p. 25,
• using the DLOADX program:
1. in the “Structure” window, “System” tab, after clicking on the partition name. Click on
the “Add” button to display the list of zones which can be assigned to the selected
partition. Click on the zone which is to be assigned to the partition.
2. in the “Zones” window, “Zones” tab, “Part.” column, enter the number of partition to
which the given zone is to be assigned.
4.3.2 Programming the EOL resistor values
As regards the zones on the control panel mainboard, in some keypads and expanders, the
value of end-of-line resistors is programmable within the range from 500 Ω to 15 kΩ (the sum
of preset values may not exceed 15 kΩ).
The value of EOL resistors for the zones on mainboard can be programmed:
• using the keypad, in the service mode, by means of EOL R1 RESISTOR, EOL R2 RESISTOR
and EOL R3 RESISTOR functions (STRUCTURE HARDWARE EOL R1 RESISTOR / EOL
R2 RESISTOR / EOL R3 RESISTOR),
• using the DLOADX program, in the “Structure” window, “Hardware” tab, after clicking on
the control panel mainboard.
The value of EOL resistors programmed for the mainboard zones applies also to the
zones in the keypads:
− INT-KLCD and INT-KLCDR with electronics version 3.2 and firmware version 2.11
(or later),
− INT-KLFR,
− INT-KSG with firmware version 1.02 (or later),
− INT-TSG,
− INT-TSH,
− INT-TSI.
