52 Programming SATEL
4.3.5 Zone types
0. ENTRY/EXIT – a delayed zone combining two functions:
entry – violation of the zone starts entry delay counting in the partition and turns on delay
for the 3. INTERIOR DELAYED type zones,
exit – violation of the zone during exit delay countdown is equivalent to the partition exit.
1. ENTRY – violation of the zone starts entry delay counting in the partition and turns on delay
for the 3. INTERIOR DELAYED type zones.
2. DELAYED – a delayed-action zone with optional signaling of delay countdown in keypads.
3. INTERIOR DELAYED – the zone operates as a delayed one when:
– violation of another zone has triggered the entry delay countdown in the partition,
– the delay will be activated using the INT-ENT entry keypad (see the INT-SCR
multifunction keypad manual),
– arm mode type 2 or 3 is active and the DELAY IN 2&3 TYPE ARMING option is enabled for
the zone.
In other situations, the zone will act as an instant one.
4. PERIMETER – instant zone, which is already armed during exit delay countdown.
5. INSTANT – instant zone.
6. EXIT – violation of the zone during exit delay countdown is equivalent to the partition exit.
7. DAY/NIGHT – if disarmed, the zone will signal violation acoustically in keypads and on
the 9. DAY ALARM, 12. SILENT ALARM and 116. INTERNAL SIREN outputs. When armed, the
zone acts as the 5. INSTANT zone.
8. EXTERIOR – a zone with alarm verification: zone violation will start counting the surveillance
time – if a second violation takes place during this time, an alarm will be triggered. If the
SURVEILLANCE TIME is not programmed (the value 0 is entered), the alarm will be generated
upon the first violation.
9. 24H TAMPER – permanently armed zone, intended for the tamper circuits. The zone
violation will additionally cause a trouble condition.
10. 24H VIBRATION – permanently armed zone, intended for working with vibration detectors.
If the partition includes the 10. 24H VIBRATION zone, starting the procedure of arming
from the LCD keypad will initiate a test of vibration detectors (the 39. TEST VIBRATION
DETECTORS output is activated and the countdown of time remained to the test end is
running).
11. 24H CASH MACHINE – permanently armed zone, intended for protection of a cash machine.
12. PANIC-AUDIBLE – permanently armed zone, intended for operating the panic buttons.
13. PANIC-SILENT – permanently armed zone, intended for operating the panic buttons.
Violating the zone will trigger a silent alarm.
14. MEDICAL – BUTTON
15. PERSONAL EMERGENCY
The zone types 14 and 15 trigger alarm signaled in the LCD keypads and on the 12. SILENT
ALARM
outputs. The names of zones and codes of events from these zones are consistent
with the Contact ID reporting format.
16...31 COUNTING C1...16 – the counting zones will signal an alarm when the number of
violations counted during a specified time period exceeds the set value (see: “Counters”
p. 57). Violations of the counting zones in armed mode can be signaled at the 9. DAY
ALARM, 12. SILENT ALARM and 116. INTERNAL SIREN outputs.
32. 24H FIRE
33. 24H FIRE – SMOKE
