38 Programming SATEL
2. A drop-down menu will be displayed. Select the “Modem - INTEGRA with ext. modem” in
it. A window will open in which modem initialization information will be displayed.
3. In the LCD keypad connected to the control panel, start the START DWNL-MOD function
([code] DOWNLOADING START DWNL-MOD). The function is available to the installer,
administrator and user having the DOWNLOADING STARTING right.
4. The control panel will call the programmed computer telephone number.
5. The DLOADX program will answer the connection automatically or the program user must
accept establishing the communication (which depends on the settings programmed in
the “Configuration” window, “Modem” tab). A suitable message will inform about the
connection being established.
3.4.2 Starting remote programming via Ethernet network
Programming through the Ethernet network is possible, if the ETHM-1 / ETHM-1 Plus module
is connected to the control panel (the RS-232 ports of control panel and module must be
connected).
Before you start the remote programming via Ethernet, make sure that the local
programming is finished.
The connection can be established in one of the following methods:
1. Initiating connection from the DLOADX program. The control panel can be programmed
from any location. If communication takes place in a wide area network, the control panel
must have a public IP address.
2. Initiating connection from the keypad (by the control panel). The control panel can be
programmed only from specified location. This method is recommended when the alarm
system owner does not want the remote programming to be carried out without its
knowledge. If communication takes place in a wide area network, the computer with
DLOADX program must have a public IP address.
3. Initiating connection by SMS message. The computer with DLOADX program must have
a public IP address. The INT-GSM module must be connected to the ETHM-1 Plus
module.
4. Establishing connection via the SATEL server. The control panel can be programmed
from any location. No public IP address is required for the control panel or the computer
with DLOADX program..
Required settings of the control panel for all methods of establishing connection:
• EXTERNAL MODEM, MODEM ISDN/GSM/ETHM and ANSWERING – ETHM/GSM options
enabled.
Required settings of the ETHM-1 Plus / ETHM-1 module for all methods of establishing
connection:
• COMMUNICATION WITH DLOADX option enabled,
• data encryption key (DLOADX KEY) programmed,
• network settings configured.
Initiating connection from the DLOADX program
Required settings of the ETHM-1 Plus / ETHM-1 module:
• programmed number of TCP port used for communication.
Required settings of the DLOADX program for direct communication with the module:
• programmed: Ethernet module address (SERVER), number of TCP port used for
communication and data encryption key (DLOADX KEY) or selected set of parameters
“LAN: ETHM-1, Address n” (settings of the ETHM-1 Plus / ETHM-1 module with address
“n” will be used).
