90 Programming SATEL
– event assignment (if STATION 1 AND 2 is selected),
– advanced options if SIA reporting format is selected.
4. If a reporting format other than CONTACT ID (FULL) or SIA (FULL) is selected:
– assign identifiers to the partitions, zones, keypads and expansion modules,
– program the codes for events which are to be reported.
5. Define the parameters of test transmissions.
6. Define the priority of GPRS reporting in the settings of INT-GSM module (INT-GSM
module connected to the control panel) or ETHM-1 Plus module (INT-GSM module
connected to the ETHM-1 Plus module).
Reporting by using the GSM module
As an external modem, the following module must be connected to the control panel
(the RS-232 ports of control panel and module must be connected):
− GSM-X,
− GSM LT-2 with firmware 2.11 (or later),
− GSM-4 with firmware 4.11 (or later),
− GSM-5.
If the GSM module is only connected to the control panel dialer terminals (TIP and
RING), the GPRS reporting settings will be ignored.
The EXTERNAL MODEM and MODEM ISDN/GSM/ETHM options must be enabled in the
control panel (see: “Telephone options” p. 68).
1. Enable the REPORTING – GPRS option.
2. Determine whether the event codes will be sent to both monitoring stations or to one of
them only (STATION 1 OR 2 / STATION 1 / STATION 2 / STATION 1 AND 2).
3. Program the following for the monitoring station to which event codes are to be sent:
– reporting format in which the codes will be sent,
– server address,
– port number,
– IP format in which the codes will be sent (SATEL or SIA-IP),
– encryption key (STATION KEY) and control panel identifier for the purposes of GPRS
reporting (GPRS KEY) if the SATEL format is selected,
– additional parameters if the SIA-IP format is selected,
– identifiers with which the events will be sent,
– event assignment (if STATION 1 AND 2 is selected),
– advanced options if SIA reporting format is selected.
4. If a reporting format other than CONTACT ID (FULL) or SIA (FULL) is selected:
– assign identifiers to the partitions, zones, keypads and expansion modules,
– program the codes for events which are to be reported.
5. Define the parameters of test transmissions.
10.2.4 SMS reporting
The TELIM format events cannot be sent as SMS messages.
1. Enable the REPORTING – ETHM/INT-GSM option.
2. Determine whether the event codes will be sent to both monitoring stations or to one of
them only (STATION 1 OR 2 / STATION 1 / STATION 2 / STATION 1 AND 2).
