SATEL INTEGRA Plus 39
Before initiating the connection, make sure that the suitable connection establishing
method is selected in the “Connection settings” window, “Connection” field.
1. Click on the button in the DLOADX program.
2. A drop-down menu will be displayed. Click in turn on “TCP/IP: DLOADX -> ETHM” and
“LAN/WAN” (WAN connection) or “LAN” (LAN connection).
3. A window will open. Click on the “Connection” button in the window.
4. The DLOADX program will inform you about establishing connection by means of
a suitable message.
Initiating connection from the keypad
If the INT-GSM module is connected to the ETHM-1 Plus module and connection over
Ethernet cannot be established, an attempt will be made to establish connection via
GPRS.
Required settings of the ETHM-1 Plus / ETHM-1 module:
• programmed: address of computer with DLOAX program (SERVER) and number of TCP
port used for communication.
Required settings of the DLOADX program for direct communication with the module:
• programmed: number of TCP port used for communication and data encryption key
(DLOADX KEY) or selected set of parameters “LAN: ETHM-1, Address n” (settings of the
ETHM-1 Plus / ETHM-1 module with address “n” will be used).
1. Click on the button in the DLOADX program.
2. A drop-down menu will be displayed. Select “TCP/IP: DLOADX <- ETHM/INT-GSM” in it.
3. In the LCD keypad connected to the control panel, start the ETHM-1 DLOADX function
([code] DOWNLOADING ETHM-1 DLOADX). The function is available to the
installer, administrator and the user having the DOWNLOADING STARTING right.
4. The DLOADX program will inform you about establishing connection by means of
a suitable message.
Initiating connection by SMS message
The INT-GSM module must be connected to the ETHM-1 Plus module. If connection
via Ethernet cannot be established, an attempt will be made to establish
communication via GPRS.
Required settings of the ETHM-1 Plus module:
• programmed: address of computer with DLOAX program (DLOADX SERVER) and number
of TCP port used for communication,
• programmed control command, which, if sent in the SMS message, will initiate connection
with the DLOADX program.
Required settings of the DLOADX program for direct communication with the module:
• programmed: number of TCP port used for communication and data encryption key
(DLOADX KEY).
1. Click on the button in the DLOADX program.
2. A drop-down menu will be displayed. Select “TCP/IP: DLOADX <- ETHM/INT-GSM” in it.
