4. 2EOL/NC – the zone supports a detector of NC type with two EOL resistors in the
circuit,
5. 2EOL/NO – the zone supports a detector of NO type with two EOL resistors in the
circuit,
6. Roller – the zone supports a roller shutter detector,
7. Vibration – the zone supports a vibration detector (also NC type detector),
8. Follow output – the zone does not support any detectors – its status depends solely on
the status of selected output (physical violations and tampers of the zone are ignored),
9. Roller 2EOL – the zone supports a roller shutter detector with two EOL resistors in the
circuit,
10. Vibration 2EOL – the zone supports a vibration detector (also NC type detector) with
two EOL resistors in the circuit,
11. 3EOL/NC – the zone supports a detector of NC type with three EOL resistors in the
circuit,
12. 3EOL/NO – the zone supports a detector of NO type with three EOL resistors in the
circuit.
Zone sensitivity – depending on wiring type:
NO, NC, EOL, 2EOL/NC, 2EOL/NO, 3EOL/NC and 3EOL/NO – the time during which the
zone must be violated, so that it can be noted by the control panel.
Roller / Roller 2EOL – 2 parameters are to be programmed (in the DLOADX program,
you should enter two numbers in the ZONE SENSITIVITY field):
Pulses duration – the time period during which a specified number of pulses must
occur (PULSES COUNT) for the zone to be violated. You can enter 0 (the pulse counter
will only be reset on arming / disarming), 1 (30 seconds), 2 (120 seconds) or 3 (240
seconds).
Pulses count – the number of pulses after which the zone will be violated. You can
program values from 1 to 8.
Vibration / Vibration 2EOL – 2 parameters are to be programmed (in the DLOADX
program, you should enter two numbers in the ZONE SENSITIVITY field):
Sensitivity – occurrence of a pulse whose duration is equal to or longer than the
defined time will cause violation of the zone. You can program values from the 3 ms
to 96 ms range (every 3 ms).
Pulses count – the number of pulses after which the zone will be violated. You can
program values from 0 to 7. If the value 0 is programmed, the pulses will not be
counted – only SENSITIVITY will be taken into account.
Output – refers to the FOLLOW OUTPUT wiring type. Indicate the number of output whose
activation will violate the zone. The output can be a virtual one.
Max. violation time / Max. door opening time – exceeding the maximum time of
violation/door opening is recognized by the control panel as a detector failure/door failure.
If the value 0 is programmed, control of this time is disabled.
Max. no violation time – exceeding the maximum time of no violation is recognized by the
control panel as a detector failure. The time will only be counted when the zone is
disarmed. If the value 0 is programmed, control of this time is disabled. The time can be
programmed in hours or minutes.
It is recommended that you program the MAX. NO VIOLATION TIME parameter, since it will
provide an additional supervision of the detector connected to the zone.
