32 Programming SATEL
Description of the parameters
Control panel settings
Options related to working in conjunction with the Ethernet module are described in section
“Telephone options” (p. 68).
Ethernet module settings
For description of parameters and options, please refer to the Ethernet module manual.
DLOADX program settings
These settings apply not only to communication via Ethernet but also via GPRS,
provided that the INT-GSM module is connected to the ETHM-1 Plus module.
TCP/IP connection: DLOADX – ETHM/INT-GSM
The settings below apply to direct communication with the module.
Connection – select the set of parameters that will be used for establishing communication:
SERVER, PORT and DLOADX KEY.
LAN/WAN – you can enter the parameters yourself. These can be parameters needed for
the Wide Area Network (WAN) or Local Area Network (LAN) communication.
LAN: ETHM-1, Address n [n=module address] – settings of the ETHM-1 Plus / ETHM-1
module with the given address will be used (the module network address will not be
read if it is downloaded from the DHCP server). These settings can only be used for the
needs of LAN communication.
Server – address of the Ethernet module. If the Ethernet module is not in the same local
network as the computer with DLOADX program, it must be a public address. You can
enter either the IP address or the domain name.
Port – the number of TCP port used for communication between the control panel and
computer with DLOADX program using the ETHM-1 Plus (INT-GSM module connected to
the ETHM-1 Plus) / ETHM-1 module. You can enter a value from 1 to 65535. Default
value: 7090.
DLOADX key – a string of up to 12 alphanumeric characters (digits, letters and special
characters), used for data encryption during communication between the control panel and
the computer with DLOADX program using the ETHM-1 Plus / ETHM-1 / INT-GSM
module.
SATEL server
The settings below apply to communication with the module via the SATEL server.
Connection – select the set of parameters that will be used for establishing communication:
ETHM-1 ID, ETHM-1 MAC and DLOADX KEY.
MAC (ETHM-1) – you can enter the parameters yourself.
Module: ETHM-1, Address n [n=module address] – settings of the ETHM-1 Plus module
with the given address will be used.
ETHM-1 ID – individual identification number assigned to the ETHM-1 Plus module by the
SATEL server.
ETHM-1 MAC – hardware address of Ethernet module.
DLOADX key – a string of up to 12 alphanumeric characters (digits, letters and special
characters), used for data encryption during communication between the control panel and
the computer with DLOADX program using the ETHM-1 Plus / ETHM-1 / INT-GSM
module.
