42 Programming SATEL
xxxx=aaaa:p= (“xxxx” – the control command to initiate establishment of communication
with DLOADX program; “aaaa” – address of the computer with DLOADX program (IP
address or domain name); “p” – TCP port) – the module is to connect to the computer
whose address has been given in the SMS message and use for communication the
TCP port given in the SMS message.
4. The DLOADX program will inform you about establishing connection by means of
a suitable message.
Establishing connection via the SATEL server
For communication via the SATEL server, the ports of 1024-65535 range are used as
outgoing ports. These ports must not be blocked.
Required settings of the INT-GSM module:
• CONNECTION VIA SATEL SERVER option enabled.
Required settings of the DLOAX program for communication via the SATEL server:
• programmed: identification number assigned to the INT-GSM module by the SATEL server
(INT-GSM ID), IMEI number of the INT-GSM module (INT-GSM IMEI) and data encryption
key (DLOADX KEY) or selected set of parameters “Module: INT-GSM, Address n” (settings
of the INT-GSM module with address “n” will be used).
1. Click on the button in the DLOADX program.
2. A drop-down menu will be displayed. Select “TCP/IP: Satel server”.
3. A window will open. Click on the “Connection” button in the window.
4. The DLOADX program will inform you about establishing connection by means of
a suitable message.
Programming via the SATEL GSM module
GSM-X module or module with LEON telephone is required:
• GSM LT-1 (firmware version 1.14 or newer),
• GSM LT-2 (firmware version 2.14 or newer),
• GSM-4 (firmware version 4.14 or newer),
• GSM-5 (firmware version 5.14 or newer).
The RS-232 ports of the control panel and GSM module must be connected.
Connection can be established by sending an SMS message to the GSM module. The
computer with DLOADX program must have a public IP address.
Required settings of the control panel:
• EXTERNAL MODEM, MODEM ISDN/GSM/ETHM and ANSWERING – ETHM/GSM options
enabled.
Required settings of the GSM module:
• programmed: address of the computer with DLOADX program, number of TCP port used
for communication, data encryption key and control command which, if sent in the SMS
message, will initiate connection with the DLOADX program,
• configured GPRS settings.
Additionally, you can enable in the module the option that will enable connection to be
established with the computer whose network address will be given in the SMS message
initiating the connection.
