23. ARM/DISARM BEEP – signals:
– starting the arming procedure (arming, if the exit delay has not been programmed) –
1 tone,
– disarming – 2 tones,
– clearing alarm – 4 tones,
– denial of arming or arming procedure failure – 7 tones.
The tone duration is approx. 0.3 seconds.
24. MONO SWITCH – controlled by users, zones or timers. Using a code, zone violation or
turning timer on will activate the output for a preprogrammed time.
25. BI SWITCH – controlled by users, zones or timers. Depending on the current status, using
a code or violating a zone will activate/deactivate the output. Turning the timer ON
activates the output, and turning the timer OFF deactivates the output.
If the 24. MONO SWITCH or 25. BI SWITCH type output is to be controlled from the
keypad, it must be assigned to a group of outputs (see: “Output groups” p. 66).
26. TIMER – the output controlled by timers.
27. TROUBLE STATUS – indicates the troubles.
28. AC LOSS (MAINBOARD) – IMMEDIATE – indicates the loss of AC power to the control panel
mainboard.
29. AC LOSS (TECHNICAL ZONE) – indicates the violations of 59. TECHNICAL-AC LOSS type
zones.
30. AC LOSS (EXPANSION MODULE) – indicates the loss of AC power to the modules with power
supply.
31. BATTERY TROUBLE (MAINBOARD) – indicates the low battery of the control panel mainboard.
32. BATTERY TROUBLE (TECHNICAL ZONE) – indicates the violations of 60. TECHNICAL-BATTERY
LOW
type zones.
33. BATTERY TROUBLE (EXPANSION MODULE) – indicates the low battery of the modules with
power supply.
34. DETECTOR TROUBLE – indicates the zone troubles.
35. TELEPHONE LINE IN USE STATUS – indicates that the telephone communication is in use.
36. GROUND START – generates a control pulse necessary for work with some types of
telephone exchange.
37. REPORTING ACKNOWLEDGEMENT – indicates the acknowledgement of reporting.
38. SERVICE MODE STATUS – indicates that the service mode is entered.
39. TEST VIBRATION DETECTORS – intended for testing the vibration detectors in one partition
(see: 10. 24H VIBRATION zone type). The output cut-off time defines the duration of testing
the vibration detectors in the selected partition.
40. CASH MACHINE BYPASS STATUS – indicates bypassing the 11. 24H CASH MACHINE type
zones in partitions with cash dispenser.
41. POWER SUPPLY – intended for supplying external devices.
42. POWER SUPPLY ON ARMED – dedicated to powering the detectors which should not be
active when the system is disarmed. Gets active when the arming procedure is started
(active during the exit delay countdown).
43. RESETABLE POWER SUPPLY – the power supply output with optional reset by the user. The
programmed cut-off time is the time during which the output will be turned off.
44. FIRE DETECTORS POWER SUPPLY – intended for supplying the fire detectors with automatic
alarm verification. Violating the fire zone will turn the power off (for the time programmed
