Section 2: General Specifications
CG4 Series Service Manual Page 2-3
MODEL NAME
CG408 DT CG412 DT CG408 TT CG412 TT
RIBBON (Be sure to use ribbon manufactured or certified by SATO)
Wind Direction
—
Face Out
Winding Method Paper core
Roll Diameter Maximum outer diameter: 38 mm (1.4”)
Core Diameter Inner core diameter: 12.7 mm (0.5”)
Length
Max. 100m (328 ft.), Do not exceed the
maximum outer diameter.
Width
Use only 110mm +/- 0.5mm
(4.33” +/- 0.01”)
PROCESSING
CPU 32 Bit RISC-CPU 133MHz
Flash ROM 4 Megabytes
SDRAM 8 Megabytes
PRINTER LANGUAGE
Standard SATO Barcode Printer Language (SBPL)
INTERFACES
Standard Configurations
Select one of the following. (The factory will provide the unit with the selected
interface.)
1) USB 2.0 (Type B) with RS-232C (D-SUB 9-pin type) or
2) USB 2.0 (Type B) with LAN (10BASE-T/100BASE-TX Automatic Switching) or
3) USB 2.0 (Type B) with IEEE1284
*The RS-232C connector can be used to connect the printer to a computer, an
optional keypad, Smart keyboard or Barcode scanner.
SENSING
Gap (Transmissive) Sensitivity Adjustable
I-Mark (Reflective) Sensitivity Adjustable
Cover Open Fixed
Ribbon End Not available
Fixed (Only available for Thermal
Transfer model)
Dispenser Fixed (Only available if installed)
Linerless label sensor Fixed (Only available if installed)
LABEL ISSUING MODES
Standard: Continuous mode, Tear -off mode, Sensor off mode
Optional mode: Dispenser mode, Cutter mode, Linerless (Nonsepa) mode
