SATO CG4 Series Service Manual

Section 4: Operation and Configuration
CG4 Series Service Manual Page 4-7
4.3 USER TEST PRINT MODE (cont’d)
4.3.1 Output Data of the User Test Print
The output data of the User Test Print shows the current settings of the printer.
These output data are printed in three parts, each with the printing area of 110mm [4.33”] (Width) x 115mm
[4.53”] (Pitch), Standard.
First print-out (Settings)
No. Print Item Contents of the print data
1 Model Printer model name CG408TT(*), CG412TT(*)
CG408DT, CG412DT
*: “T” is printed for thermal
transfer print.
“D” is printed for direct
thermal print.
2 Offset Offset value (Vertical and
horizontal directions)
(H)±300 (V)±300 DOT
3 Pitch Offset Pitch offset value ±099 DOT
4 Cut Offset Cut position offset value ±099 DOT
5 Peel Offset Peel off position offset value ±099 DOT
6 Tear Off Offset Tear off position offset value ±099 DOT
7 Label Size Label size (Pitch/Width) (P)**** x (W)*** DOT
8 Print Speed Print speed 50mm/s
75mm/s
100mm/s
9 Print Darkness Print darkness 1A~5A
10 Operation mode Operation mode CUT/ NONE SEPA/
TEAR OFF/ DISPENSER/
CONTINUOUS
11 Sensor Type Sensor type Gap
I-Mark
None
12 Paper End Search Paper end detection method TAG/ ROLL
13 Zero Slash Zero slash ON/ OFF
14 Proportional Pitch Proportional pitch ON/ OFF
15 Buzzer Buzzer ON/OFF
16 Initial Feed Initial feed ON/ OFF
17 Protocol-codes Protocol code setting value
(Standard / Nonstandard)
Nonstandard/ Standard
18 Option waiting time Option waiting time 500 to 20000 ms
19 Num of formats stored Number of formats stored *
20 Printer mode Printer mode ONLINE/ STANDALONE
