SATO CG4 Series Service Manual

Section 4: Operation and Configuration
Page 4-8
CG4 Series Service Manual
4.3 USER TEST PRINT MODE (cont’d)
Second print-out (Protocol code setting values)
Third print-out (Interface)
USB and RS-232C interface on board
No. Print Item
1STX
2ETX
3 ESC
4ENQ
5CAN
6 NULL
7 OFFLINE
8 AUTO ONLINE
9 ZERO SLASH Zero slash
10 EURO Euro code
No. Print Item Contents of the print data
1 Selected Interface In-use interface USB / RS-232C / Keypad /
Scanner
2 Interface 1 Interface 1 USB
3 Buffer Type Buffer type Multi
4 Protocol Protocol Driver
5 Serial No. Serial No. Serial No./ None
6 Interface 2 Interface 2 RS-232C
Communication parameters (19200.8.N.1)
Baud rate (bps)
9600, 19200, 384000
Data length (bit)
8, 7
Parity
N, O, E
Stop bit (bit)
1 2
7 Buffer Type Buffer type 1 item / Multi
8 Protocol Protocol ER/RS
XON/XOF
Driver
Status3
