SPC filter:
Filter time for SPC values “mean value” and “variance”
Mean value Imitt:
Feed rate mean value exponentially filtered using the
SPC filter time related to nominal feed rate.
Variance:
Feed rate variance related to the square of nominal feed
rate.
Belt load QMAX:
Maximum belt load during last few hours limited by SPC
time related to nominal belt load.
Time Q < MIN:
Total time during which belt load was below Qmin
(Parameter F 05), evaluated over the past few hours
(SPC time).
Last taring results (max. 5):
Results (total tare) of last 5 zero point or tare corrections,
related to nominal belt load.
Test weight check on :
Date and time of last check using check weight,
performed using “Weight Check CW” setting program.
BIC active:
indicates whether automatic belt influence
compensation is active, or not.
Events report:
lists number and type of events occurred after last
printout.
If no report has been printed yet, counting starts from
time of power-up.
Counter 3:
Totalizing counter 3
Belt skew:
indicates change in belt length in % of total belt length
(Parameter D06).
Belt drift:
indicates belt drift in cm.
Feed Rate Diagram
Printed automatically after status report, the feed rate
diagram shows the current feed rate value in percent
of nominal feed rate. The report period is determined
by Parameter K 05 “SPC Time” .
The actual diagram resolution is higher than shown in
sample.
Feed rate 50 dots for nominal feed rate
Time : 32 dots for time K 05
Units : t/h, h
Initialisation : upon power-up and change of
Parameter K 05.
Symbol “>” : Feed rate exceeds 140 %
0837
INTECONT PLUS VBW
Control
BV-H2214 GB 15
Transmission to third parties and reproduction of
this documentation are not permitted.
SchenckProcess GmbH reserves all rights of
ownership and copyrights.
Technische
Redaktion PDE-RD
Feed Rate in Percent Pnenn
0 20 40 60 80 100 120 140 %
- 6h * 5,000 t/h
- 5h * 10,000 t/h
- 4h * 20,000 t/h
-3h >
- 2h * 40,000 t/h
- 1h * 50,000 t/h
- 0h * 50,000 t/h
