B07 FMZ 1 Unit
Range: ------- t
-----.- t
----.-- t
---.--- t
------ t*10
----- t*100
-- -----kg
-----.- kg
----.-- kg
---.--- kg
Default:-------t
Lets you determine the display format for Counter 1,
all batch values and pulse weighting.
If no external counter is present, set Parameter B08 to
0.
B08 FMZ 1 Pulse Dur.
Range: 0....1000 ms Default: 0 ms
Lets you determine output pulse length of external
totalizing counter. Pulse weighting corresponds to the
smallest display digit of Counter 1
(Parameter B07).
B08 < 10 ms : Pulse output is disabled.
All pulses not yet output still are
deleted.
At nominal feed rate the output frequency is:
PNENN = nominal feed rate in kg/h or t/h
Zmin = smallest display digit of Counter 1
(B 07) in kg or t
Select Zmin (B07) so that f does not exceed
10 Hz.
In addition, pulse duration B08 must be smaller than
1/f.
B09 FMZ 2 Unit
same as B08, however, for Counter 2
B10 FMZ 3 Unit
same as B08, however, for Counter 3
B11 DO Pulse Counter
Range: —
DO
Default: —
The impulse output of totalizing counter 1 can now
also be output via a digital output. The impulse output
of INTECONT on plug X6, pins 8-11 is still used with
default value “—“ and the configured output is used
instead with the alternative DO.
The impulse duration is still determined with the B08
parameter. Readings less than 10 ms block the output
total and readings up to 1 second are set to 1 second
when a digital output is used.
B12 Pulse Weighting
Range: 0.00 – 100000.00 kg Default: 0.00 kg
The weighting of an output impulse on the impulse
output of totalizing counter 1 can now be set to be
freely selected. The weighting of an impulse
corresponds to the smallest possible digit of counter 1
with default value 0.00 (refer to parameter B07).
0837
INTECONT PLUS VBW
Parameterization
BV-H2214 GB 53
