MAX = Relay output for limit value monitoring
Open = MAX value exceeded up
Feed rate, belt load, or belt speed, can be
monitoring separately for excess of MIN
and MAX values.
FAULT = Relay output for alarms
Open = Alarm
FULL = Relay output for full feed in batching
mode
Closed = full feed
DRIBBLE = Relay output for dribble feed
Closed = dribble feed
MOTOR = Control output for belt drive
Closed = ON
PREF. = Control output for prefeeder
Closed = On
RELEASE
=
Release signal for totalization
H = Release
ON/OFF = Start scale and totalization.
High = ON
OFF = Stop
Low = STOP
COUNTER= Pulse output for connection of external
totalizing counter
For simple measuring tasks, with constant belt speed,
speed transducer D can be omitted.
0837
INTECONT PLUS VBW
Overview
BV-H2214 GB 3
Transmission to third parties and reproduction of
this documentation are not permitted.
SchenckProcess GmbH reserves all rights of
ownership and copyrights.
