Block L : Communication Fieldbus
L01 Protocol Type
Range: NO
MODBUS COMP.
S5-BCC COMP.
MODBUS
PROFIBUS DP
DEVICENET
MODBUS/TCP
Default: NO
Every protocol requires an optional interface card to
be present.
“COMP” identifies the compatible protocols.
L02 TIMEOUT Host
Range: 1...600s Default: 10s
If timeout value exceeds zero, a message from host
system is expected to arrive during set time.
L03 Comm. Error Host S9
Range: IGNORE
W1 (Warnung 1)
W2 (Warnung 2)
A (Alarm)
Default: ALARM
If no message is received during the time set by
Parameter L02, event message S9 “Data Link Host” is
output.
0837
INTECONT PLUS VBW
Parameterization
BV-H2214 GB 67
Transmission to third parties and reproduction of
this documentation are not permitted.
SchenckProcess GmbH reserves all rights of
ownership and copyrights.
Technische
Redaktion PDE-RD
Protocol Type MODBUS/
MB-COMP
.
S5-BCC Comp. MODBUS PROFIBUS DP DeviceNet MODBUS TCP ETHERNET IP
VEG VSS VSS VSS VPB 020/8020 VCB
020/8020
VET 020 VET 022
BLOCK L Default MODBUS/
MB-COMP.
PROFIBUS
DP
DEVICENET MODBUS/
TCP
ETHERNET/
IP
S5-BCC Comp.
L 01 Protocol Type NO x x x x x x
L 02 TIMEOUT Host 5 s x x x x x x
L 03 Comm. Error Host IG (S 09) x x x x x x
L 04 Word sequence I:std/L:std x x x x
L 05 Byte sequence High - Low x x
L 06 Configuration FIXED x x x
L 07 Address 1 x
L 08 Resolution 4096 x
L 09 Physical attributes RS 485 x
L 10 Baud Rate 9600 x x
L 11 Data format 8-E-1 x x
L 12 Adresse 16 x
L 13 FLOAT-FORMAT IEEE x x
L 14 Address 63 x
L 15 Baud Rate 125K x
L 16 S5-Physical attributes RS422 x
L 22 Hardware VxB020 x x
Tabelle der aktiven Parameter abhängig vom Protokolltyp.
