Block S: Secondary display DLZ
S01 DLZ active
Range: YES
NO
Default: NO
A large-scale display such as DLZ055 or DLZ110 can
be connected at the serial interface on the VEA600V
option card (plug X10). Procedure DDP8861 is used.
Selecting DLZ active suppresses all printing outputs
and the secondary display is triggered instead. The
value shown on the lowest line of INTECONT Plus is
always outputted.
Display on
INTECONT Plus
Character on
the secondary
display
meaning
I I feed rate [kg/h] or [ t\h]
Ir i
relative feed rate [%] rated feed
rate
Q Q belt load [kg\m]
Qr q
relative belt load [%] rated belt
load
v v belt speed [m/s]
Z1 1 counter 1 [kg] or [t]
Z2 2 counter 2 [kg] or [t]
Z3 3 counter 3 [kg] or [t]
ZB B batching setpoint [kg] or [t]
Zd R batching residual value [kg] or [t]
Nb N consecutive batching number
ZI F actual batching value [kg] or [t]
Zbn b reloading setpoint [kg] or [t]
Zdn r
residual batching value of the
quantity reloaded [kg] or [t]
The DLZ055/110 secondary display can only show the
dimensions kg and t.
If the letter field of the secondary display is illuminated
as a full-surface block, this indicates that the value
shown is invalid. Either it is not possible to show the
desired format or INTECONT is in service operation.
The VLZ20100/VLZ20045 secondary displays can also
be connected, although they do not have any display for
identification and the validity of the outputted
measurement.
The usage of other secondary displays that understand
the DDP8861 protocol has to be examined in specific
cases.
Note: the BVH2015 Manual on Secondary/Large-Scale
Displays
S02 Baud rate
Range: 1200
2400
4800
9600
19200
38400
Default: 9600
S03 Data format
Range: 7 Bit, Even Parity
8 Bit, No Parity
Default: 8Bit NO
S04 Physics
Range: RS232
RS485
RS422
Default:: RS232
0837
VBW INTECONT PLUS
Parameterization
BV-H2214 GB 80
