7.30
SEL-387-0, -5, -6 Relay Instruction Manual Date Code 20170601
Serial Port Communications and Commands
SEL ASCII Protocol Details
(Continued from previous page)
50P21P = OFF 50P22P = OFF
50P23P = 0.10 50P24P = 0.70
51P2P = 0.70 51P2C = U2 51P2TD = 3.50 51P2RS = Y
51P2TC =1
Press RETURN to continue
50Q21P = OFF 50Q22P = OFF
51Q2P = 1.05 51Q2C = U2 51Q2TD = 3.50 51Q2RS = Y
51Q2TC =1
50N21P = OFF 50N22P = OFF
51N2P = OFF
DATC2 = 15 PDEM2P = 1.40 QDEM2P = 0.20 NDEM2P = 0.20
50P31P = 1.40 50P31D = 0.00 50P31TC =1
50P32P = OFF
50P33P = 0.10 50P34P = 0.80
51P3P = 0.80 51P3C = U2 51P3TD = 1.30 51P3RS = Y
51P3TC =1
50Q31P = OFF 50Q32P = OFF
51Q3P = OFF
50N31P = OFF 50N32P = OFF
51N3P = OFF
Press RETURN to continue
DATC3 = 15 PDEM3P = 1.40 QDEM3P = 0.20 NDEM3P = 0.20
TMWDG = 1 VWDG = 230.00 XTYPE = 3 TRTYPE = Y
THwr = 65 NCS = 1
MCS11 = 100.0
DTMP = 15 TRDE =0
NTHM = 2 AMB = THM1 OIL1 = THM2
TOT1 = 100 TOT2 = 100 HST1 = 200 HST2 = 200
FAAL1 = 50.00 FAAL2 = 50.00 RLOLL = 50.00 TLOLL = 50.00
CSEP1 = 15
ILIFE = 180000 EDFTC = Y
TDURD = 9.000 CFD = 60.000
TR1 =50P11T + 51P1T + 51Q1T + OC1 + LB3
TR2 =51P2T + 51Q2T + OC2
TR3 =50P31 + 51P3T + OC3
TR4 =87R + 87U
TR5 =0
ULTR1 =!50P13
ULTR2 =!50P23
Press RETURN to continue
ULTR3 =!50P33
ULTR4 =!(50P13 + 50P23 + 50P33)
ULTR5 =0
52A1 =IN101
52A2 =IN102
52A3 =IN103
52A4 =0
CL1 =CC1 + LB4 + /IN104
CL2 =CC2 + /IN105
CL3 =CC3 + /IN106
CL4 =0
ULCL1 =TRIP1 + TRIP4
ULCL2 =TRIP2 + TRIP4
ULCL3 =TRIP3 + TRIP4
ULCL4 =0
ER =/50P11 + /51P1 + /51Q1 + /51P2 + /51Q2 + /51P3
OUT101 =TRIP1
OUT102 =TRIP2
OUT103 =TRIP3
OUT104 =TRIP4
Press RETURN to continue
OUT105 =CLS1
OUT106 =CLS2
OUT107 =CLS3
SCEUSE 46.8
GR1CHK A526
=>>
