To avoid circuitry malfunctioning due to electrical load increase, never utilize
CONVERGENCE ADJUSTMENT (Line Convergence Adjustment in particular) for
adjusting screen size changes.
There is no means to restore the Convergence Adjustment data once stored, to its
original state. To avoid changing the screen size by erroneously using convergence
adjustment, do not perform the green Line Convergence Adjustment.
As such, be sure to perform the adjustment work from this page onward by the
Technical staff and the Location's Maintenance Man who are well versed in such
adjustment work. In the Static Convergence Adjustments, if satisfactory adjustments
can not be performed, do not make another convergence adjustments inadvertently.
Contact the office herein stated or where the product was purchased from.
● To avoid making the adjustment work ineffective, do not press the RESET button
during adjustment.
● To discontinue adjustment work, keep pressing the TEST button for approximately
3 seconds at the stage before storing the adjustment data by pressing the WRITING
button.
● Should the screen be abnormally disturbed by noise due to static electricity, etc.,
turn the power off without storing the adjustment data.
ADJUST MODE
SUB VSIZE
SUB HSIZE
SUB BRIGHT
EXIT
Adjustment menu used in the factory.
CONVERGENCE ADJUSTMENT (manual color matching)
● Pressing the ▲ or ▼ PIC - ADJ button in the
Convergence Adjustment mode status will
display the Adjustment Menu shown right. Do
not utilize this Adjustment Menu as this is the
one applied at the factory.
Adjusting this menu causes the Customer's
adjustment range to be deviated.
Should the menu shown right be displayed by mistake, first choose EXIT by using
either ▲ or ▼ PIC - ADJ button and then press the SET button.
CAUTION!
STOP
IMPORTANT!
To Next Page
