4. NAME OF PARTS
FIG. 4
TABLE 4
Width × Depth × Height Weight
PTV 88.19 in × 21.9 in × 65.7 in 220.4 lb
PTV BASE 47.2 in × 24.4 in × 12.2 in 57.3 lb
BILLBOARD 46.06 in × 16.14 in × 15.16 in 39.68 lb
MAIN CABINET 44.9 in × 42.91 in × 39.76 in 216.05 lb
When assembled 47.24 in × 66.14 in × 67.8 in 557.77 lb
AC UNIT
BILLBOARD
PTV .
50 TYPE PROJECTION DISPLAY
MAIN CABLINET
COIN CHUTE DOOR
CASHBOX DOOR
PTV BASE
IC CARD UNIT
GUN CONTROLLER
