FIG. 9. 3 d GUN ADJUSTMENT screen
●
● ● ●
●
GUN ADJUSTMENT
PLAYER 1 PLAYER 2
-> TOP 5 233 -> TOP 5 233
LEFT -318 17 LEFT -318 17
CENTER -10 15 CENTER -10 15
RIGHT 242 34 RIGHT 242 34
BOTTOM -10 -204 BOTTOM -10 -204
DEFAULT DEFAULT
CANCEL CANCEL
CURSOR CURSOR
SELECT WITH SERVICE BUTTON
AND PULL TRIGGER
PRESS TEST BUTTON TO EXIT
D. GUN ADJUSTMENT
Select GUN ADJUSTMENT to display the following screen.
This screen allows you to adjust the gun using the five calibration targets (TOP, LEFT, CENTER,
RIGHT, BOTTOM). Use each target to calibrate as follows.
Use the standard gun controller, carefully aim at the correct target and pull the trigger to calibrate the
value. Select between the calibration targets with the 1P and 2P START buttons or SERVICE button.
Details for each item are as follows.
● TOP x y: Set the TOP value.
The number on the left (x) is the horizontal component, and the number on the
right (y) is the vertical component. Aim the controller at the TOP target (circle)
and pull the trigger to set the value. This will not affect horizontal calibration.
● LEFT x y: Set the LEFT value.
The number on the left (x) is the horizontal component, and the number on the
right (y) is the vertical component. Aim the controller at the LEFT target and
pull the trigger to set the value. This will not affect vertical calibration.
● CENTER x y: Set the CENTER value.
The number on the left (x) is the horizontal component, and the number on the
right (y) is the vertical component. Aim the controller at the CENTER target
and pull the trigger to set the CENTER value.
● RIGHT x y: Set the RIGHT value.
The number on the left (x) is the horizontal component, and the number on the
right (y) is the vertical component. Aim the controller at the RIGHT target and
pull the trigger to set the RIGHT value. This will not affect vertical calibration.
To Next Page
